| SJSZ80/156 conical double screw plastic extruder | ||||||||||||||||||||||||

SJSZ - 80 conical double screw plastic extruder, deserve to go up after proper and aux, rigid polyvinyl chloride powder can be directly processed into large pipe, plate, profiles etc, and also can be used for PVC powder granulation Machine barrel and screw The screw diameter: 80/156 mm Machine barrel and screw material: 38 crmoal nitriding processing The screw rotation speed: 3.5-34 RPM Heating and power section number: barrel 5; 36 kw resistive heating Barrel cooling fan power and cooling area: 0.25 x 4 areas L exhaust SZ - 2.2 KW type 1 * 4 by using a vacuum pump The main motor power: 55 kw adopt ac frequency converter control L quantitative feeding machine capacity: 600 * 400, material: stainless steel polishing Feeding machine: 1.5 KW L electrical components: temperature control instrument for both CARDS, Contactor 'Siemens' brand, Choose "sanli" brand button, indicator light, Air switch 'delixi' brand | ||||||||||||||||||||||||
